IOS-XR: L2VPN BVI VRRP Bundle-Ethernet configuration to ACI Fabric
12.02 2024 | by massimilianoEsempio di architettura reale: ASR9K-R02 configuration interface BVI77 description transit-ACI vrf PIPPO ipv4 address 10.10.1.10 255.255.255.248 ! l2vpn bridge-group ACI […]
Esempio di architettura reale:
ASR9K-R02 configuration
interface BVI77
description transit-ACI
vrf PIPPO
ipv4 address 10.10.1.10 255.255.255.248
!
l2vpn
bridge-group ACI
bridge-domain DMZ-PIPPO
interface Bundle-Ethernet 77.77
routed interface BVI77
!
interface bundle-ethernet 77
description Transit-VL77-DMZPIPPO-ACI-BL101/102
interface bundle-ethernet 77.77 l2transport
encapsulation dot1q 77
!
interfce gi0/0/1/0
bundle id 77 mode active
negotiation auto
interface gi0/0/1/1
bundle id 77 mode active
negotiation auto
!
router vrrp
interface bvi77
address-family ipv4
vrrp 77
preempt delay 10
priority 200
address 10.10.1.9
!
ASR9K-R03 configuration
interface BVI77
description transit-ACI
vrf PIPPO
ipv4 address 10.10.1.11 255.255.255.248
!
l2vpn
bridge-group ACI
bridge-domain DMZ-PIPPO
interface Bundle-Ethernet 77.77
routed interface BVI77
!
interface bundle-ethernet 77
description Transit-VL77-DMZPIPPO-BL101/102
interface bundle-ethernet 77.77 l2transport
encapsulation dot1q 77
!
interfce gi0/0/1/0
bundle id 77 mode active
negotiation auto
interface gi0/0/1/1
bundle id 77 mode active
negotiation auto
!
router vrrp
interface bvi77
address-family ipv4
vrrp 77
address 10.10.1.9
!
